PEN NEEDLE ASSEMBLY MACHINE
페이지 정보
작성자 Automatic 댓글 0건 조회 4,859회 작성일 14-09-02 16:57본문
1. Dimension : 13,500L x 4,260W x 2,500H
2. Weight : About 5,500Kg
3. Electric Power : AC 3Px220/380V, N.G 50/60Hz
4. Electric Power Consumtion : About 22Kw
5. Air Pressure : 6Kg/㎠
6. Air Consumtion : About 1,300L/min
7. No. Of Worker : 4~5Persons
8. Production Capacity : 27,000 ~ 30,000Pcs/Hour
9. Main Frame Material : Base : SS41 Cr Hard Coating
Bady : AL6061
10. Hub Supply Type : Shut Type
11. Electric Discharge Treatment : 25,000V( Transformer)
12. Cannula Supply Type : Lift Type
13. Bonding Type : Wheel Type (Epoxy or U.V)
Servo Controller
14. Hardening Tunnel
15. Inspection : Reversed, Point, Blockage , Bending, Non- Cannula
16. Ejection Of Bad-Needle : Auto Ejector
17. Silicon Coating : Dip Type
18. Needle cap : Shut type
19. Hub assembly : Shut type
20. Paper supply unit : Arm type
21. Sealing part : Heater type ,upper&side sealing
2. Weight : About 5,500Kg
3. Electric Power : AC 3Px220/380V, N.G 50/60Hz
4. Electric Power Consumtion : About 22Kw
5. Air Pressure : 6Kg/㎠
6. Air Consumtion : About 1,300L/min
7. No. Of Worker : 4~5Persons
8. Production Capacity : 27,000 ~ 30,000Pcs/Hour
9. Main Frame Material : Base : SS41 Cr Hard Coating
Bady : AL6061
10. Hub Supply Type : Shut Type
11. Electric Discharge Treatment : 25,000V( Transformer)
12. Cannula Supply Type : Lift Type
13. Bonding Type : Wheel Type (Epoxy or U.V)
Servo Controller
14. Hardening Tunnel
15. Inspection : Reversed, Point, Blockage , Bending, Non- Cannula
16. Ejection Of Bad-Needle : Auto Ejector
17. Silicon Coating : Dip Type
18. Needle cap : Shut type
19. Hub assembly : Shut type
20. Paper supply unit : Arm type
21. Sealing part : Heater type ,upper&side sealing
