Multiple sample needle assembly machine
페이지 정보
작성자 manager 댓글 0건 조회 6,613회 작성일 09-09-18 16:25본문
1. Dimension : 9,400L x 5,200W x 2,550H
2. Weight : About 4,000Kg
3. Electric Power : AC 3Px220/380V, N.G 50/60Hz
4. Electric Power Consumtion : About 25Kw
5. Air Pressure : 6Kg/Cm2
6. Air Consumtion : About 1,400L/min
7. No. of worker : 2~3Persons
8. Production Capacity : 20,000Pcs/Hour
9. Main Frame Material : Base : SS41 Cr Hard Coating Bady : AL6061
10. Hub supply : Shup supply
11. Cannula Supply Type : Lift Type
12. Bonding Type : Wheel Type( Epoxy ) Servo Controller
13. Hardening Tunnel
14. Inspection : Point, Closed cannula
15. Ejection Of Bad-Needle : Auto Ejector
16. Silicon Coating : Dip Type
17. Needle cap : Auto. Supply system Shut type
18. Gasket cap : Shut type
19. Upper cap : Auto. Supply system Shut type
20. Zig : 35pins/300Pcs
